Digital Miniature Nephroscope

Digital Miniature Nephroscope (8.5/12Fr)

Technical parameters:

》 Model: WY-DW01

》 Outer diameter: 8.5/12Fr

》 Working length: 250 mm

》 Channel: 6.3Fr

》 Viewing angle: 12°

Characteristic:

》 Wide-angle field of vision, a high definition of 160,000 pixels, wide imaging range and clear image quality.

》 The use of photoelectric image technology of high-transmittance columnar crystal and semi-rigid integrated hard lens allow the endoscopic body to bend slightly and deliver good resilience;

》 Integrated video plug, which also suitable for Digital endoscope image processor, allows flexible&rigid endoscopes switch freely, conveniently and quickly.

》 Suitable for holmium laser or ultrasonic lithotripsy

Auto pressure control design

Distinctive ovally shaped body design can effectively control intraoperative, pressure, improve surgical safety and reduce postoperative complications.

Single-hand operation design

Single-hand operation design provides more convenience in the operation to achieve efficient completion of surgery.

Can be equipped with negative pressure sheath for lithotripsy

Can be equipped with negative pressure sheath of 15/16Fr to remove renal calculus without no residue.

Dual sealing system

The in&external Dual valve sealing system design allows it to automatically open and close during instrument entry and exit, showing excellent sealing performance.
